Technical parameters
Vacuum tubes used: 6N8P×4 EL34×4
Rated output power: 20W+20W (RMS three-stage working state)
32W+32W (RMS super-linear working state)
Frequency response of the whole machine: 10Hz~50KHz (-1.5dB)
Input sensitivity: 260mV
Volume of the whole machine: 43cm (length)×19.5cm (height)×39cm (depth)
Power supply voltage: ~220V±5% (50Hz)
Working conditions: Temperature: 0℃~40℃
Humidity: 20%~80%Storage conditions: Temperature: -20℃~70℃
Humidity: 20%~90%Harmonic distortion: 1% (1KHz)
Signal-to-noise ratio: 88dB (A initiative)
Input impedance: 100KΩ
Output impedance: 4Ω, 8Ω
Net weight: 27kg
Power consumption of the whole machine: 280W
